Belt Oil Skimmer for Water Treatment

The Belt Oil Skimmer is a high-efficiency, durable floating oil removal equipment specifically designed for water treatment scenarios. It adopts high-quality 304 stainless steel as the main body material and a filter belt-type flocked fiber as the core oil-absorbing component, ensuring excellent corrosion resistance, oil absorption performance, and service life. The equipment operates by driving the flocked fiber belt to continuously contact the water surface, efficiently adsorbing floating oil and oil-water emulsions, and then scraping off the oil through a precision scraper, realizing continuous and automatic floating oil removal.

With the advantages of simple structure, stable operation, low energy consumption, and easy maintenance, the Belt Oil Skimmer can flexibly adapt to different water volumes and oil content conditions. It effectively solves the problems of low manual oil removal efficiency, incomplete oil removal, and secondary pollution, and is widely used in industrial wastewater treatment, oil storage and transportation, and environmental emergency treatment. It ensures that the treated water meets the required discharge or recycling standards.

Inquiry

Write a Review

Parameters

Component	Material Specification	Core Advantages	Application Significance
Main Body & Frame	304 Stainless Steel (Standard); 316L Stainless Steel (Corrosive Environment)	● Excellent corrosion resistance to acid, alkali, and salt-containing wastewater; ● High mechanical strength, anti-deformation, and long service life (≥8 years); ● Smooth surface, easy to clean, and compliant with environmental protection requirements.	Adapt to harsh working environments such as industrial wastewater and marine oil spill treatment, avoiding equipment rust and damage caused by corrosive media.
Oil-Absorbing Belt	Filter Belt-Type Flocked Fiber (Polyester Base + Special Flocking Coating)	● High oil absorption rate (oil absorption capacity is 15-20 times its own weight); ● Strong oil-water selectivity, almost no water absorption; ● Wear-resistant, aging-resistant, and washable for repeated use; ● Good flexibility, adapting to different water surface fluctuations.	Ensure efficient and targeted absorption of floating oil, reduce energy consumption for subsequent oil-water separation, and lower operating costs.
Scraper & Sealing Parts	Teflon-Coated Stainless Steel (Scraper); Food-Grade Silicone (Sealing Ring)	● Scraper: High hardness, wear-resistant, and can scrape oil completely without damaging the oil-absorbing belt; ● Sealing parts: Good elasticity, oil-resistant, and prevent oil leakage during scraping.	Guarantee the oil scraping efficiency (scraping rate ≥98%), avoid oil residue on the belt, and ensure the continuity of the oil removal process.

Working process flow chat

Application Scenarios

Industrial Wastewater Treatment

Applicable to wastewater from machinery manufacturing (cutting fluid wastewater), metal processing (cooling water wastewater), food processing (fried oil wastewater), and petrochemical (oil refining wastewater) industries. It is mainly used in oil-water separation tanks, sedimentation tanks, and adjusting tanks to remove floating oil and light oil, reducing the oil content of incoming water for subsequent biochemical treatment (oil content ≤50 mg/L after treatment).

Oil Storage & Transportation Industry

Used in oil storage tanks, oil depots, and oil terminals. It can remove floating oil on the surface of tank cleaning wastewater and rainwater in the tank area, preventing oil from entering the sewage system and causing pipeline blockage or environmental pollution. It is also suitable for emergency oil removal in small oil spill accidents in oil tank areas.

Marine & Port Environmental Protection

Suitable for small and medium-sized oil spill treatment in ports, docks, and inland waterways (oil spill volume ≤50 m³). The 316L stainless steel version can resist seawater corrosion, and the flocked fiber belt can quickly absorb diesel, gasoline, and crude oil, reducing the impact of oil spills on aquatic ecosystems.

Cooling Water System

Used in open cooling water towers and circulating cooling water systems of power plants, chemical plants, and data centers. It removes oil leaked from equipment (such as pump seals) in the cooling water, preventing oil from adhering to the heat exchange surface and affecting heat exchange efficiency, and avoiding the growth of oil-decomposing bacteria causing biological fouling.

Municipal & Environmental Emergency

Applied to oil removal in municipal sewage treatment plants (grease trap auxiliary oil removal) and emergency treatment of oil spills in rivers, lakes, and reservoirs. It can be quickly deployed to the accident site, and the mobile version can realize on-site rapid oil removal, reducing environmental pollution.

Core Functions & Working Principle

Efficient Oil Absorption & Scraping

The flocked fiber belt has strong oil absorption capacity, and the precision scraper can completely scrape off the adsorbed oil, with an oil removal efficiency of ≥95% for floating oil with a viscosity of ≤100 cSt.

Continuous Automatic Operation

Driven by a frequency conversion motor, it can operate 24 hours a day continuously. The oil absorption belt speed can be adjusted (0.5-5 m/min) according to the oil content, realizing adaptive oil removal and saving energy.

Corrosion & Wear Resistance

The stainless steel main body and wear-resistant flocked fiber belt adapt to harsh working environments, reducing maintenance frequency and extending equipment service life.

Easy Operation & Monitoring

Equipped with a simple control panel, it supports manual/automatic switching. The optional liquid level sensor and oil content monitor can realize automatic start-stop and remote monitoring of oil removal effect.

Low Energy Consumption & Environmental Protection

The power of the main motor is only 0.37-2.2 kW, and the oil-absorbing belt can be reused after cleaning, reducing material consumption and operating costs. The collected oil can be recycled, realizing resource reuse.

Working Principle

The Belt Oil Skimmer adopts a "adsorption - scraping - collection" three-stage oil removal mechanism, and the specific working process is as follows:

Oil Absorption Stage

The lower part of the flocked fiber oil-absorbing belt is immersed in the water to be treated (immersion depth can be adjusted 5-50 mm). Due to the lipophilic and hydrophobic characteristics of the flocked fiber, the floating oil on the water surface is quickly adsorbed on the surface of the belt, while almost no water is absorbed.

Oil Scraping Stage

2.The oil-absorbing belt adsorbed with oil is driven by the motor to rotate upward. When passing through the precision scraper (the gap between the scraper and the belt is ≤0.1 mm), the oil on the belt is completely scraped off. The Teflon coating of the scraper ensures that the oil does not adhere to the scraper surface.

Oil Collection Stage

The scraped oil flows into the oil collection tank through the oil guide groove, and then is discharged to the oil storage barrel or oil-water separator through the oil discharge pipe for further treatment or recycling. The oil-absorbing belt after oil scraping continues to rotate and immerse in water to start the next cycle.

Adaptive Adjustment

The frequency conversion motor adjusts the rotation speed of the oil-absorbing belt according to the oil content (detected by the oil content sensor) or manually set parameters. When the oil content is high, the speed is increased to improve oil removal efficiency; when the oil content is low, the speed is reduced to save energy.

Installation & Maintenance Requirements

Site Requirements

The installation site should be flat and solid, with a bearing capacity ≥1.5 times the net weight of the equipment. For indoor installation, ensure good ventilation; for outdoor installation, configure rainproof and sunshade facilities. The distance from the equipment to the edge of the water tank/pool should be 300-500 mm, and a maintenance space of ≥600 mm should be reserved around the equipment.

Installation Position

The oil-absorbing belt should be aligned with the main floating oil area of the water surface. The immersion depth of the belt should be adjusted according to the oil layer thickness (generally 10-20 mm for thin oil layers, 30-50 mm for thick oil layers). The oil collection tank should be placed lower than the scraper to ensure smooth oil flow.

Power Supply Connection

The power supply voltage should be stable within ±5%, and an independent circuit breaker and grounding device should be configured (grounding resistance ≤4Ω). For outdoor or wet environments, use waterproof cables and connectors to meet the protection level requirements.

Commissioning

After installation, manually rotate the oil-absorbing belt to check for jamming; adjust the scraper gap to ensure that the oil is scraped clean without damaging the belt; test run for 2 hours, check the oil removal efficiency and equipment operation status, and adjust the belt speed according to the actual oil content.

Daily Maintenance

Check the oil level in the oil collection tank and empty it in time to avoid oil overflow; clean the surface of the oil-absorbing belt with a soft brush (for sticky oil) to prevent oil accumulation affecting oil absorption; check the tightness of the belt (adjustable via tensioning device if loose); record the equipment operation time and oil removal amount.

Weekly Maintenance

Inspect the scraper for wear (replace if the gap exceeds 0.2 mm); lubricate the motor bearing and transmission chain with lubricating oil (use lithium-based grease); clean the oil guide groove and oil collection tank to remove oil residues and impurities.

Monthly Maintenance

Check the oil-absorbing belt for wear, aging, or damage (replace if the oil absorption rate decreases by more than 30%); inspect the motor and reducer for abnormal noise or overheating; tighten the bolts of the main body and frame to prevent loosening caused by vibration.

Quarterly Maintenance

Disassemble the scraper and clean the sealing ring (replace if there is oil leakage); check the frequency converter and control panel for normal operation; test the oil removal efficiency with standard oil samples and adjust the scraper gap or belt speed if necessary.

Annual Maintenance

Replace the oil-absorbing belt (regardless of wear for safety); overhaul the motor and reducer (replace worn parts such as bearings and seals); perform anti-rust treatment on the stainless steel main body (polish and apply anti-rust oil for coastal or high-corrosion environments).

After-Sales Service & Warranty

Warranty Period

1 year for the whole machine, 2 years for core components (oil-absorbing belt, motor, scraper). During the warranty period, free replacement of defective components and on-site maintenance services are provided (excluding damage caused by improper operation).

Technical Support

Provide 24-hour response technical support via email and phone. A professional technical team is available to solve operational and maintenance problems. For complex installation scenarios, on-site technical guidance is provided.

On-Site Service

For faults that cannot be solved remotely, on-site service will be arranged within 48 hours for domestic customers and 72 hours for overseas customers (in major industrial regions). Emergency maintenance services can be provided for key projects.

Spare Parts Supply

Spare parts warehouses are set up in China, the United States, Germany, and Singapore to provide common spare parts (oil-absorbing belt, scraper, sealing ring, lubricating oil) in a timely manner. The delivery cycle is 3-7 working days.

Training Service

Provide free on-site training for 2-3 operators, covering equipment installation, commissioning, operation, routine maintenance, and fault diagnosis. Provide English operation manuals, maintenance manuals, and training videos. Customized training courses can be provided for large-scale procurement projects.

Tell Us More About Your Project !

If you have any questions about water treatment systems, please feel free to contact QILEE.

Stable equipment

Mature technology

Automated operation

Simple operation

Do You Have any Questions? Welcome to Leave Us a Message.

Model	Max. Oil Removal Capacity (L/h)	Oil Absorption Belt Width (mm)	Overall Dimension (L×W×H, mm)	Motor Power (w)	Net Weight (kg)	Main Body Material
QL-OS-10	35-110	100	300×480×268	40	30	304 Stainless Steel
QL-OS-15	90-270	150	377×608×380	40	45	304 Stainless Steel
QL-OS-20	70-220	200	450×608×380	60	55	304 Stainless Steel
QL-OS-30	140-340	300	800×775×524	90	90	304 Stainless Steel
QL-OS-40	80-500	400	800×785×524	90	110	304 Stainless Steel
