Submersible sewage pump

Transform your water treatment and mixing processes with our advanced submersible mixers, designed for seamless integration and relentless reliability. Featuring a robust dual mechanical seal, stainless-steel construction, and maintenance-free bearings, these mixers excel in demanding environments - from activated sludge tanks to bioreactors and beyond.

Our hydrodynamically optimized swept-back impellers ensure superior mixing efficiency with self-cleaning capability, while premium materials like enhanced PU vanes and stainless-steel fittings resist corrosion and wear. With built-in leakage and overtemperature protection, along with IP68-rated waterproofing and continuous 24-hour operation, these units deliver durable performance, minimal downtime, and consistent flow control in municipal, industrial, and environmental applications.

Inquiry

Write a Review

Features

Motor

Squirrel-cage, induction motors are F class insulation, motor protection grade is IP68.

Mechanical seal

The mechanical seals protect the motor from contacting the pumping liquids. Two seals are in series with each other and individually work to provide the motor with a dual protection.

Auto-setter (options)

To allow pump for easy installation, maintenance & reparation, as it is no need to empty the tank first.

Non-clog impeller

Well statically & dynamically balanced Non-Clog impeller is designed to allow sizable spherical solids to pass the flow passage easily without clogging. It adopts rigorous technics so that vibration and noise can be farthest reduced.

Leakage detector

Built-in leakage detector in the oil chamber can detect leakage from the damage of the mechanical seal. (Less than 15 kW options, No less than 15kW standard). Built-in leakage detector in the wiring box and motor cavity of large power pumps can check if a leakage in it. The leakage detector offers pump an automatic protection (Not standard, No less than 132 kW options)

Heat-protector

Built-in heat protector in motor, can prevent the motor from burning out, overload & overheating. (Less than 15 kW options, No less than 15 kW standard). Built-in heat protector in bearing, when the bearing is abnormal and the temperature rises to disconneting temperature, the protector automatically cut off power supply to protect the bearing. (Not standard, no less than 18.5 kW options).

Cooling house (options)

Pumps make use of inner pressure of pump cavity to make liquid continully entering in space between cooling house and motor outer, to take away the heat of the motor. to make sure the regular work of the pump in low water level (No less than 18.5 kW options).

Application

● Wastewaterlift station.

● Municipal wastewatertreatment plant.

● Building wastewater treatment system.

● Livestockanimal nusbardy wastewater treatment system.

● Hospital,school, community,etc. wastewater treatment system.

● Food, paper, mining, textile, leather, chemical industry,etc.wastewater treatment system.

● Water purification system.

Construction

NO.	Name	Material
NO.	Name	GB	JIS
1	Neck bolt	OCr18Ni9	SUS304
2	Heat-Protector	-	-
3	Motor cover	HT200	FC200
4-1	Bearing	-	-
4-2	Bearing	-	-
5	Cooling house flange	Q235A	SS400
6	Shaft	2Cr13	SUS420
7	Rotor	-	-
8	Stator	-	-
9	Cooling house	Q235A	SS400
10	Bearing cover	HT200	FC200
11	Motor casing	HT200	FC200
12	Bracket	HT200	FC200
13	Leakage detector	-
14-1	Mechanical seal	C-Al2O3	C-Al2O3
14-2	Mechanical seal	SiC-SiC	SiC-SiC
15	Oil cover	HT200	FC200
16	Washer	OCr18Ni9	SUS304
17	Impeller nut	OCr18Ni9	SUS304
18	Seal-ring	ZCuSn10Pb5	LBC2
19	Strainer	HT200	FC200
20	Impeller	HT200	FC200
21	Pumpcasing	HT200	FC200
22	Bottom cover	HT200	FC200
23	Pail piping	Q235A	SS400
24	Flange setter	HT200	FC200
25	Slide	HT200	FC200
26	Duckfoot	HT200	FC200
27	Discharge	Q235A	SS400
Different model has a little difference,Materials can be selected according to the requirement of the customer.
