Activated Carbon Powder Auger Screw Conveyor 500L/h 1yr
Activated Carbon Auger Dust Vertical Powder Screw Conveyor
Vertical Powder Screw Conveyor Features:
Adaptable for industry applications for large quantity of dry chemical (such as lime)
Pneumatic transported to life the chemical by chemical conveyor against free dust
Silo volume: 10~100m3
Dosing quantity: 50~2000L/h dry power
Equipped bin bottom activation device
Equipped powder metering and transporting device
Equipped bag filter
Material of construction: carbon steel epoxy Painted (stainless steel is as option)
Option: inlet water control unit, lime dissolving tank and mixed, etc.
Vertical Powder Screw Conveyor Features:
| Specification | Silo | Screw | Dissolving tank | Total powder | Floor area |
| Capacity(m3) | Diameter/Height | Treating Capacity(kg/h) | Diameter/Height | kw | Length*Width |
| QT-10 | 1.9m/8.0m | 1-50 | 1m/1.3m | 6 | 5.0m*3.0m |
| QT-20 | 2.5m/8.0m | 5-100 | 1.7m/1.5m | 8 | 6.0m*3.5m |
| QT-30 | 2.9m/8.5m | 10-200 | 2.0m/1.8m | 10 | 8.0m*4.0m |
| QT-50 | 2.9m/11m | 50-500 | 2.4m/2.2m | 14 | 10.0m*5.0m |
| QT-70 | 4.0m/11m | 100-1000 | 2.6m/2.5m | 20 | 12.0m*6.0m |
| QT-100 | 5.0m/11m | 200-1500 | 3.0m/3.0m | 25 | 13.0m*6.0m |
| QT-150 | 6.0m/11m | 200-2000 | 3.0m/3.0m | 28 | 13.0m*8.0m |
| QT-200 | 6.0m/13m | 200-3000 | 3.0m/3.0m | 30 | 13.0m*8.0m |
| QT-300 | 8.0m/13.5m | 500-5000 | 3.0m/3.0m | 30 | 15.0m*8.0m |
Vertical Powder Screw Conveyor Accessories:
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
Stable equipment
Mature technology
Automated operation
Simple operationDo You Have any Questions? Welcome to Leave Us a Message.
