Mini Power Press Machine: Sludge, 1yr Warranty, Motor & PLC

Compact mini power press for sludge with a built-in motor, PLC control, and a 1-year warranty. Automated PLC and robust motor give precise, fast, and low-effort pressing in a small footprint, ideal for labs or small plants. Key selling points: reliable warranty support, energy- and space-saving design, simple operation and maintenance, and consistent dewatering performance.

brand name:

QILEE

Shipping:

Support Sea freight

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-1(sets):15(days),>1(sets):To be negotiated(days)

Place of Origin:

China

Inquiry

Write a Review

Reference Weight(kg)

1420~3150

Powder Consumption(kw)

1100~2800

Water Content's Rate(%)

75~85

Inlet Consistency(%)

s.s.0.4~0.8%

Dried Sludge(kg/hr)

84~450

Treating Capacity(kg/h)

13.5~49

Processing Type

desalination

Power(W)

1 kW

Product name

Small Power Press Machine

Voltage

220 V, 380 V

weight (kg)

1420

productivity

13.5~49

warranty

1 Year

place of origin

Shanghai, China

core components

Motor, PLC

machinery test report

Provided

video outgoing-inspection

Provided

Compact Automated Reliable Dewatering

Efficient, low-energy QTBH sludge dewatering machine delivers fast, low‑moisture cake separation using Swiss filter cloth, automatic cloth-centering and PLC-controlled motor operation for stable, low-noise performance and a 1-year warranty. Built from rust‑proof SUS304 stainless steel with a compact footprint and safety monitoring, it simplifies operation, lowers maintenance and adapts to multiple capacity models. Ships in standard export cartons within 3–20 days and arrives ready-to-install with motor & PLC and a professional stainless‑steel finish suited for municipal, industrial and food‑industry use.

Compact Automated Sludge Press

The QTBH sludge dewatering machine Mini Power Press combines a SUS304 stainless steel frame, imported Swiss filter cloth, air-chamber automatic belt correction and a PLC-controlled motor with a one-year warranty to deliver corrosion resistance, long service life and low-noise, low-energy operation. Engineered for sludge and slurry-water separation across municipal and industrial applications, it provides high throughput with multiple models and belt widths (treating ranges roughly 10–49 m3/hr and dried sludge outputs of about 55–450 kg/hr), low cake moisture, flexible operation and built-in safety monitors with automatic stop functions. Its compact structure—featuring belt widths from 1000–2000 mm, integrated drum thickener and compatibility with polymer dosing, pumping and washing accessories—ensures easy installation, low maintenance costs and stable, efficient dewatering performance.

Mini Motorized Sludge Press

The QTBH sludge dewatering machine is a compact mini power press made of SUS304 stainless steel, equipped with Swiss-imported filter cloth and an air-chamber automatic cloth deviation correction device for reliable sludge separation in industrial, municipal, food and agricultural applications. PLC-controlled operation with motor drive, low energy consumption, high efficiency and low noise (≤75 dB(A)), plus safety monitoring, deliver stable, flexible operation, low-moisture cake and easy maintenance. Available in multiple models (QTBH-1000 to QTBH-2000) and belt widths, it comes with a 1-year warranty and integrates easily with sludge pumps, dosing systems and washing pumps for diverse wastewater treatment needs.

◎ product nicety 1

◎ product nicety 2

◎ product nicety 3

Efficient Compact Reliable Automated

The QTBH sludge dewatering machine combines precision engineering and a compact footprint, using stainless-steel construction, an energy-efficient motor, and integrated PLC controls to deliver reliable small-scale sludge handling. It automates continuous dewatering with high solids capture and low moisture output, while offering easy operation, fast maintenance, and a one-year warranty for dependable after-sales support. Key features and advantages include PLC automated control for consistent performance, a robust motor for steady pressing, low energy consumption, compact installation, simple cleaning, and readily available spare parts to minimize downtime and operating costs.

Material introduction

The QTBH sludge dewatering machine features a principal frame and all sludge-contact parts made from SUS304 stainless steel, providing high strength, excellent corrosion resistance and rust-free operation in harsh environments. Its filtration system uses Swiss-imported filter cloth for superior durability and long service life, protected by an air-chamber automatic deviation correction device to maintain even wear. Key components like the driving motor and PLC are installed in robust, sealed enclosures to minimize vibration and moisture ingress, ensuring reliable, low-maintenance performance.

◎ Main Frame & Slurry-Contact

◎ Filtration & Wear Components

◎ Drive, Control & Enclosures

FAQ

What kinds of sludge and materials can the Mini Power Press handle?

The Mini Power Press is designed for dewatering a wide range of low- to medium-solid sludges, including municipal sewage sludge, food‑processing sludge, paper mill sludge, oily or industrial sludges and similar slurry-like wastes. Very dilute feeds (extremely low solids) should be pre‑thickened for best performance. Always check the machine’s technical datasheet for exact feed solid concentration, particle size and abrasive/corrosive limits before processing unusual materials.

How should I install and commission the machine?

Install on a level, rigid foundation and anchor with the recommended bolts. Connect mains power to the motor according to the nameplate voltage and frequency, earth the machine, and hook up the PLC control panel and any auxiliary lines (hydraulic, pneumatic, feed and discharge piping). Perform an empty-run check to verify rotation direction, PLC functionality, limit switches and emergency stop operation, then test with a controlled feed while monitoring pressure and motor load. Follow the supplier’s commissioning checklist and have an authorized technician perform the first setup if you’re unsure.

How do I operate the PLC controls and adjust basic parameters?

The PLC provides start/stop, emergency stop, cycle timing, pressing pressure (or speed) and alarm display. Use the operator interface to set cycle duration and motor/run sequences; do not change advanced control parameters unless trained. Always observe safety interlocks and password protections—save or back up PLC programs before making changes. If remote monitoring or data logging is available, configure it during commissioning and consult the manual for alarm code meanings.

What routine maintenance is required and how often?

Daily: check for leaks, unusual noises, and clear any visible blockages; verify electrical indicators and emergency stop. Weekly: inspect and clean feed/discharge paths and check belt/drive tension. Monthly: lubricate bearings and sliding parts per the lubrication chart, inspect seals/scrapers and tighten fasteners. Quarterly/annually: change hydraulic or gear oil (if applicable), inspect motor and gearbox, back up PLC configuration and replace worn consumables. Keep a maintenance log and replace wear parts proactively.

What common issues should I expect and how can I troubleshoot them?

Low cake dryness—check feed solids (may need pre‑thickening), increase pressing pressure or extend cycle time. Low throughput—inspect for clogged feed, worn scrapers, or incorrect speed settings. Motor overload/overheating—verify supply voltage, reduce feed load, check bearings and ventilation. PLC alarms—note error codes and consult the manual; reboot only if instructed. For mechanical leaks or severe faults, stop the machine and contact qualified service; avoid improvising repairs that void warranty.

What does the 1‑year warranty cover and how do I request service?

The one‑year warranty typically covers manufacturing defects in workmanship, structural components, the motor and PLC under normal use for 12 months from delivery. It usually excludes normal wear items (seals, scrapers, gaskets), damage from misuse, improper installation, lack of maintenance, corrosion from aggressive chemicals, or unauthorized modifications. To request service, contact your supplier with the machine serial number, purchase invoice and photos or descriptions of the problem; follow their instructions for diagnostics and authorized repair. Keep records of installation and maintenance to speed any claim.

Tell Us More About Your Project !

If you have any questions about water treatment systems, please feel free to contact QILEE.
