Pellet Vacuum Powder Transfer System, 500 L/h, 1yr Warranty

Shipping:

Support Sea freight

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-1(sets):60(days),>1(sets):To be negotiated(days)

Place of Origin:

China

Inquiry

Write a Review

Structure

Conveyor System

Floor area Length*Width

5.0m*3.0m

Total powder

6kw

Dissolving tank Diameter/Height

1m/1.3m

Treating Capacity(kg/h)

1-50

Silo Diameter/Height

1.9m/8.0m

Silo volume(m3)

Processing Type

desalination

After-sales Service Provided

Online support

Power(W)

1 kW

Product name

Vacuum Powder Transfer System

Voltage

220 V, 380 V

weight (kg)

1000

productivity

500L/Hour

warranty

1 Year

PRODUCT CATEGORIES

→ VIEW ALL

Pellet Vacuum Powder Transfer System with 1 Year Warranty and 500L/Hour Productivity

Sludge dewatering machine

Screw filter press

Powder dosing system

Industrial chemical mixer

Chemical dosing pump

Sludge drying machine

Industrial RO water system

Pellet Vacuum Powder Transfer System

Product Description

Pellet Vacuum Powder Transfer System with 1 Year Warranty and 500L/Hour Productivity

Vacuum Powder Transfer System Features:
Adaptable for industry applications for large quantity of dry chemical (such as lime)
Pneumatic transported to life the chemical by chemical conveyor against free dust
Silo volume: 10~100m3
Dosing quantity: 50~2000L/h dry power
Equipped bin bottom activation device
Equipped powder metering and transporting device
Equipped bag filter
Material of construction: carbon steel epoxy Painted (stainless steel is as option)
Option: inlet water control unit, lime dissolving tank and mixed, etc.

Vacuum Powder Transfer System Features:

Specification	Silo	Screw	Dissolving tank	Total powder	Floor area
Capacity(m3)	Diameter/Height	Treating Capacity(kg/h)	Diameter/Height	kw	Length*Width
QT-10	1.9m/8.0m	1-50	1m/1.3m	6	5.0m*3.0m
QT-20	2.5m/8.0m	5-100	1.7m/1.5m	8	6.0m*3.5m
QT-30	2.9m/8.5m	10-200	2.0m/1.8m	10	8.0m*4.0m
QT-50	2.9m/11m	50-500	2.4m/2.2m	14	10.0m*5.0m
QT-70	4.0m/11m	100-1000	2.6m/2.5m	20	12.0m*6.0m
QT-100	5.0m/11m	200-1500	3.0m/3.0m	25	13.0m*6.0m
QT-150	6.0m/11m	200-2000	3.0m/3.0m	28	13.0m*8.0m
QT-200	6.0m/13m	200-3000	3.0m/3.0m	30	13.0m*8.0m
QT-300	8.0m/13.5m	500-5000	3.0m/3.0m	30	15.0m*8.0m

Pellet Vacuum Powder Transfer System with 1 Year Warranty and 500L/Hour Productivity

Vacuum Powder Transfer System Accessories:

Pellet Vacuum Powder Transfer System with 1 Year Warranty and 500L/Hour Productivity

PACKAGE:

Standard export carton packing.

DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
