Piston Water Small Hydraulic Pump Dosing 2-4900 L/h 10 Bar

This Chemical Dosing Pump delivers precise, low‑pulsation metering for water and wastewater treatment—ideal for pH adjustment, flocculation and disinfectant dosing with ±2% stability and a 10:1 turndown. Its compact, robust piston hydraulic design, PP/PVC/PVDF/316SS liquid ends, PTFE diaphragm and self‑cleaning check valves handle 2–4900 L/h at up to 10 bar and tolerate viscous or corrosive fluids. Built for long service life with heavy‑duty worm gears, multiple control options (manual, 4–20mA, frequency inverter) and shipped in standard export cartons with 3–20 day delivery for quick deployment.

High-Precision Compact Dosing Pump

This Chemical Dosing Pump is a piston small hydraulic pump delivering 2–4900 L/h flow, up to 10 bar discharge pressure, a 10:1 turndown and ±2% stability accuracy, with a 3 m suction lift, 45°C max liquid temperature and capability to handle viscosities up to 1200 cP. Designed for water and industrial treatment tasks such as pH adjustment, flocculation, polymer dosing, hypochlorite disinfection and dye handling, it offers precise metering, leak-resistant operation via a special valve seat and self-cleaning check valves, and configurable pump heads for high-viscosity, pulp or corrosive media. Robust structural features include variable eccentric stroke adjustment, sliding bearings and high-strength worm gear for low pulsation and long-term stability, multiple control options (manual, electric stroke controller or frequency inverter with 4–20 mA I/O) and a selectable liquid end of PP/PVC/PVDF/316SS with PTFE diaphragm and glass/ceramic/316SS check balls.

The Piston Water Small Hydraulic Pump is a versatile Chemical Dosing Pump for municipal tap water, swimming pools, urban sewage and industrial effluent, delivering 2–4900 L/h at up to 10 bar with stability accuracy of ±2% and a 10:1 turndown ratio. It handles liquids up to 45°C and viscosities up to 1200 cP, with PTFE diaphragms, interchangeable liquid end materials (PP, PVC, PVDF, 316SS), glass/ceramic/316SS check balls, self-cleaning valves and specially sealed seats to prevent leakage. Adjustable stroke control is available manually, via electric stroke controller (4–20 mA) or frequency inverter, while robust worm gears, sliding bearings and variable eccentric stroke minimize pulsation for stable long-term operation.

◎ Compact Precision Doser

◎ Durable Chemical Construction

◎ Versatile Control Options

Precise Powerful Durable Efficient

Built with decades of fluid-handling expertise, the Piston Water Small Hydraulic Pump Dosing 2-4900 L/h 10 Bar is engineered for precise, reliable metering in demanding environments. As a compact Chemical Dosing Pump it delivers adjustable flow from 2 to 4900 L/h at up to 10 bar, offering stable piston actuation, corrosion-resistant wetted parts, and low pulsation for accurate chemical feed and minimal maintenance. Key advantages include high-pressure capability for long pipe runs, an energy-efficient hydraulic drive, simple calibration and serviceability, and robust materials for extended life in industrial, water treatment, and process dosing applications.

The Chemical Dosing Pump features corrosion-resistant liquid end options—PP and PVC for general service, PVDF and 316 stainless steel for aggressive or high-purity media—paired with a PTFE diaphragm for strong chemical and thermal resistance. Ball check valves come in glass, ceramic or 316SS and a specially designed valve seat with a self-cleaning check structure minimizes leakage and fouling across demanding chemistries. These material selections, combined with a robust drive unit and high-viscosity-capable pump head, ensure reliable metering up to 10 bar while handling temperatures to 45°C and viscosities up to 1200 cP.

◎ PP/PVC Liquid End

◎ PVDF Liquid End

◎ 316 Stainless Steel Liquid End
