brand name:

QILEE

Shipping:

Support Sea freight

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-1(sets):15(days),>1(sets):To be negotiated(days)

Place of Origin:

China

Inquiry

Write a Review

Reference Weight(kg)

1420~3150

Powder Consumption(kw)

1100~2800

Water Content's Rate(%)

75~85

Inlet Consistency(%)

s.s.0.4~0.8%

Dried Sludge(kg/hr)

84~450

Treating Capacity(kg/h)

13.5~49

Processing Type

desalination

Power(W)

1 kW

Product name

Stainless Steel Dehydrator

Voltage

220 V, 380 V

weight (kg)

1420

productivity

13.5~49

warranty

1 Year

place of origin

Shanghai, China

core components

Motor, PLC

machinery test report

Provided

video outgoing-inspection

Provided

Industrial Stainless Steel Dehydrator Dewatering Equipment with Motor & PLC 1 Year Warranty 13.5-49 Kg/h Capacity

PRODUCT CATEGORIES

→ VIEW ALL

Industrial Stainless Steel Dehydrator Dewatering Equipment with Motor & PLC 1 Year Warranty 13.5-49 Kg/h Capacity

Sludge dewatering machine

Screw filter press

Powder dosing system

Industrial chemical mixer

Chemical dosing pump

Sludge drying machine

Industrial RO water system

Industry Machine Price Dewatering Equipment Stainless Steel Dehydrator

Product Introduction

Industrial Stainless Steel Dehydrator Dewatering Equipment with Motor & PLC 1 Year Warranty 13.5-49 Kg/h Capacity

The pictures are for your reference only, please subject to practicality.

Stainless Steel Dehydrator Features:

1.The principal part adopts stainless steel as its material and possesses high strength. It is rust-less.

2. The filter cloth imported from Swiss, to provide the best performance and long service life.

3. Air chamber type automatic deviation correction device is set to assure stable running of the filter cloth.

4. Great product capability, good washing effect, flexible operation, low containing moisture in cake and low maintain expense

5. Low energy consumption,high efficiency ,low revolutions,low noise≤75dB(A)

6. Safety system monitor the entire working environment,automatic stopping devices to satisfy the need of operation security.

Stainless Steel Dehydrator selection of models:

Model		QTBH-1000	QTBH-1250	QTBH-1500	QTBH-1500L	QTBH-2000
Belt Width(mm)		1000	1250	1500	1500	2000
Low Consistency	Treating Capacity(m3/hr) Inlet Consistency(s.s.0.4-0.8%)	13.5-17.5	17.5-22.5	21-27	27.5-35.5	37.5-49
Low Consistency	Dried sludge(kg/hr)	55-112	70-144	85-172	110-228	150-312
Middle Consistency	Treating Capacity(m3/hr) Inlet Consistency(s.s.0.8-1.5%)	10.5-13.5	12.5-17.5	16-21	20.5-27.5	30-37.5
Middle Consistency	Dried sludge(kg/hr)	84-158	100-188	128-240	164-308	240-450
Water Content’s Rate(%)		75-85	75-85	75-85	75-85	75-85
Powder Consumption (HP)	Driving Motor	1/2	1/2	1/2	1	1
	Disposal Agitator Motor	1/4	1/4	1/2	1/2	3/4
	Drum Thickener	3/4	1	3/4*2	3/4*2	1*2
Lower Collecting Tray for Pressed Filtrate		None	None	None	None	None
External Dimensions (Reference)(mm)	L	2700	2800	2900	3500	3500
	W	1550	1800	2150	2150	2650
	H	2500	2500	2500	2600	2700
Base Dimension L1*W1(mm)		2100*1330	2100*1580	2100*1830	2450*1900	2580*2400
Reference Weight(kgs)		1420	1680	2100	2550	3150

Stainless Steel Dehydrator Treatment Flowchart:

Industrial Stainless Steel Dehydrator Dewatering Equipment with Motor & PLC 1 Year Warranty 13.5-49 Kg/h Capacity

Stainless Steel Dehydrator Application:

1. Sludge dewatering of various industrial waste water.
2. Sludge dewatering of butchery, husbandry.
3. Slurry and water separation in food& beverage industry, chemical industry, mining and other industries.
4. Sludge dewatering of city sewage, excretion, water purifying industries.

Industrial Stainless Steel Dehydrator Dewatering Equipment with Motor & PLC 1 Year Warranty 13.5-49 Kg/h Capacity

Stainless Steel Dehydrator Structure:

Industrial Stainless Steel Dehydrator Dewatering Equipment with Motor & PLC 1 Year Warranty 13.5-49 Kg/h Capacity

FAQ

What’s the application scope of sludge dewatering machine ?

It is widely applied in wastewater treatment in industrial, chemical, municipal and so on.

What’s the material of sludge sludge dewatering machine ?

It is SUS304.

What’s the equipment used together with sludge dewatering machine ?

Sludge pump, polymer dosing pump, washing pump, air compressor.

How to choose the model?

Advise us the sludge source, treating capacity, solid content rate, then we could choose the suitable model for you. Please put forward if you have special requirements.

PACKAGE:

Standard export carton packing.

DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
