Vacuum Screw Conveyor with Motor for Activated Carbon (SS)

The Vacuum Screw Conveyor with Motor for Activated Carbon (SS) is a compact stainless-steel conveyor that moves powdered or granular activated carbon under vacuum. A motor-driven screw inside a sealed tube gently feeds material with minimal dust and spillage, keeping the process clean and safe. It is corrosion-resistant, easy to clean, and ideal for continuous or intermittent dosing.

Usage scenarios:

- Feed activated carbon into water and wastewater treatment filters or contactors for adsorption and purification.

- Transfer and dose powdered carbon in chemical, pharmaceutical, or industrial processes where dust control and contamination prevention are critical.

- Serve pilot plants, labs, and small production lines needing precise, hygienic conveyance of activated carbon.

brand name:

QILEE

Shipping:

Support Sea freight

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-1(sets):60(days),>1(sets):To be negotiated(days)

Place of Origin:

China

Inquiry

Write a Review

Floor area Length*Width

12.0m*6.0m

Total powder

20KW

Dissolving tank Diameter/Height

2.6m/2.5m

Treating Capacity(kg/h)

100-1000

Silo Diameter/Height

4.0m/11m

Silo volume(m3)

10-300

Weight (KG)

1000

Medium

Water

Max Working Pressure(MPa)

Material

Stainless Steel, carbon steel epoxy Painted(stainless steel is as option)

key selling points

High Productivity

Product name

Screw Conveyor For Powder

warranty

1 Year

place of origin

Shanghai, China

core components

Motor

machinery test report

Provided

video outgoing-inspection

Provided

Here are three four-word subtitle options:

As reliable Activated carbon dosing equipment, this vacuum screw conveyor with motor provides precise, continuous, dust‑free metering and pneumatic transfer to ensure consistent process performance and reduced downtime. Made from epoxy‑painted carbon steel with a stainless‑steel option, compact silo profiles and modular footprints, and fitted with bag filters, bin‑bottom activation and a motorized screw, it delivers industrial durability and easy maintenance. Shipped in standard export packaging with quick lead times (3–20 days) and configurable capacities plus optional inlet‑water control or dissolving tanks, it streamlines installation and scaling for high‑volume powder dosing applications.

Motorized Vacuum Screw Conveyor

This stainless-steel vacuum screw conveyor with motor serves as Activated carbon dosing equipment, delivering sealed vacuum suction and a powered screw drive for precise, dust-free transfer with flexible silo integration. Built-in bin-bottom activation, metering and bag-filtering systems, plus optional inlet-water control or dissolving/mixing units, provide accurate volumetric dosing, continuous operation and minimized environmental contamination. Robust epoxy-coated carbon-steel construction (with stainless option), modular screw assemblies and a compact, scalable footprint offer corrosion resistance, easy maintenance and straightforward plant integration for industrial chemical and water-treatment applications.

Motorized Vacuum Carbon Conveyor

The Vacuum Screw Conveyor with Motor (SS) is a robust solution for handling powder activated carbon, offering silo volumes from 10 to 100 m3 and dosing capacities ranging 50–2000 L/h. Equipped with a bin-bottom activation device, powder metering and transporting system, bag filter and optional stainless-steel construction, this Activated carbon dosing equipment ensures pneumatic, low-dust transfer and precise metering. Optional inlet water control and dissolving tanks enable lime or chemical mixing and scalable integration across multiple capacity models.

◎

Efficient Hygienic Precise Conveying

Engineered as a stainless-steel vacuum screw conveyor with motor, this unit was developed by a specialist team with decades of industrial conveying experience to ensure sanitary fabrication, precision welding and a robust motorized drive. It functions as a closed, motor-driven dosing and conveying system that gently transfers and meters activated carbon while the vacuum-sealed design minimizes dust, cross-contamination and material loss. Key highlights and features—high dosing accuracy, adjustable screw speed, corrosion-resistant SS construction, easy-to-clean removable components, low-maintenance motor and PLC-compatible controls—make it ideal as Activated carbon dosing equipment for water treatment and filtration plants.

Material introduction

The Vacuum Screw Conveyor with Motor for Activated Carbon (SS) is constructed primarily from corrosion‑resistant stainless steel (SS) for hygienic powder handling and long-term durability, with carbon steel epoxy‑painted options for cost‑sensitive installations. Key internal components such as the auger/screw and liners are made from heavy‑duty stainless steel to resist abrasion from activated carbon and ensure reliable performance in Activated carbon dosing equipment. Chemical‑resistant seals, gaskets and optional bag filters complete the material specification to maintain vacuum integrity, minimize dust emissions and simplify cleaning and maintenance.

◎ material introduction 1

◎ material introduction 2

◎ material introduction 3

FAQ

What is a Vacuum Screw Conveyor with Motor for Activated Carbon (SS) and how does it work in typical applications?

It is a stainless-steel (SS) enclosed screw (auger) conveyor combined with a vacuum inlet and a powered drive. The vacuum helps draw activated carbon powder into the inlet while the rotating screw transports it under negative pressure to discharge points. Typical uses are dust‑tight transfer, metered feeding, and reclaiming of activated carbon between hoppers, filters, reactors, packaging stations or dosing systems while minimizing fugitive dust.

In which application scenarios is this conveyor most useful for activated carbon?

It’s ideal wherever dry, dusty activated carbon needs contained transfer or controlled dosing: filling and emptying bulk bags, moving carbon from filtration units to storage, feeding carbon into reactors or adsorption beds, transferring product to packaging lines, or reclaiming from hoppers and dust collectors. Its vacuum feed is especially valuable where dust containment and clean material pickup are required.

Is this SS vacuum screw conveyor suitable for all forms of activated carbon (powder, granules, pellets)?

Generally yes for powders and small granules—vacuum screw conveyors are well suited to fine, free‑flowing materials. Large pellets or highly irregular lumps may require pre-screening or a different conveyor geometry to avoid bridging. Very moist or sticky carbon can cling and reduce flow; those cases may need conditioning (drying) or alternate conveying methods. Confirm with the supplier for specific particle size and bulk density ranges.

What features should I expect for integration, control and throughput in a process line?

Expect a motorized gearbox with optional VFD for variable speed control so you can precisely meter feed rate. The unit typically includes a vacuum inlet/filter housing, sealed connections to hoppers or bags, service access ports and sensors (vacuum/pressure gauge, level switches). Throughput depends on screw diameter/pitch, speed and material properties—consult the manufacturer with your required t/h or kg/h for accurate sizing.

How is cleaning and maintenance handled, considering activated carbon is abrasive and adsorptive?

Stainless steel construction reduces contamination and wear. Design features to look for: quick‑open access covers, removable screw or liners for inspection, replaceable wear parts, and accessible seals. Avoid aggressive wet cleaning if carbon will adsorb moisture—dry purge, vacuuming or compressed‑air blowout are common. Regularly inspect seals, screw flights and liners for abrasion and replace worn parts to maintain performance.

What safety and regulatory considerations are important when conveying activated carbon with this equipment?

Activated carbon can generate combustible dust and adsorb vapors—address ignition and dust hazards. Use explosion‑protected motors and electrical components where required (ATEX/IECEx or local codes), ensure proper grounding, avoid sources of ignition, and provide pressure relief or explosion venting if applicable. Filtration, HEPA or spark detection/interception can reduce emissions risk. Always follow local safety regulations and consult with your safety/engineering team and the conveyor vendor for appropriate certification and safeguards.
