Automatic PAC Dosing System SUS304 1000L Agitator 220/380V

Automatic PAC Dosing System SUS304 1000L Agitator 220/380V is a stainless-steel (SUS304) dosing unit with a 1000 L tank, built-in agitator and automatic controls for precise PAC feeding. Key selling points: SUS304 corrosion resistance for long life, large 1000 L capacity for continuous work, strong agitator for even mixing, accurate automatic dosing to cut chemical waste, and 220/380V power compatibility for flexible installation. Compact and low-maintenance, it saves labor and running costs while keeping water treatment stable.

brand name:

QILEE

Shipping:

Support Sea freight

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-1(sets):30(days),>1(sets):To be negotiated(days)

Place of Origin:

China

Inquiry

Write a Review

Machine Weight(kg)

550

Machine Dimensions(mm)

2438*1300*1850

Agitator(HP)

1/2*3

Speed Variable(HP)

1/4

Hopper Volume(L)

Production Capacity(L/hr)

2000

material

SUS304

Capacity

1000 L

key selling points

Automatic

Power (kW)

1.29 .72.54kW

dimension(l*w*h)

2438*1300*1850mm

product type

Chemical

material processed

Chemicals

mixer type

Agitator

voltage

220 V, 380 V

Power

1.29

Product name

Pac Dosing System

weight (kg)

550

warranty

1 Year

place of origin

Shanghai, China

core components

Motor

machinery test report

Provided

video outgoing-inspection

Provided

Here are three concise 4-word subtitle options — pick the one that fits your tone:

The QPL3 powder dosing machine delivers automated, precise PAC/PAM dosing with a 1000L SUS304 agitator and imported components to ensure consistent treatment efficiency and minimize chemical waste. Its sleek stainless-steel cabinet, compact hopper shape, and touch-screen controls provide durable quality, easy operation, and space-saving installation while supporting 220/380V power. Packed in standard export cartons with 3–20 day delivery, this system speeds sludge conditioning and industrial wastewater clarification with stable, low‑maintenance performance.

Here are three concise 4-word subtitle options:

The QPL3 powder dosing machine is an automatic PAC dosing system constructed from SUS304 stainless steel with a 1000L agitator and 220/380V power options, integrating a powder hopper, variable-speed metering feeder and touch-screen/PLC message output for coordinated operation. It provides precise, metered powder feeding for PAM/PAC dissolution to guarantee treatment effectiveness, reduce chemical waste and support municipal or industrial wastewater and sludge conditioning. Using imported components, a compact attractive appearance and robust structural design, the unit enables reliable continuous dosing, easy adjustment and low-maintenance operation.

Automatic PAC SUS304 Dosing

The QPL3 powder dosing machine is an automatic PAC dosing system made from SUS304 stainless steel with a 1000 L agitator and 220/380V power supply. It features precise powder feeding with a variable-speed metering feeder, imported components, and touch-screen controls to ensure accurate dosing and minimize chemical waste. Built for wastewater treatment tasks like municipal and industrial sludge coagulation, the unit delivers reliable performance with an attractive, easy-to-operate design.

◎ Stainless Steel Construction

◎ Precise Dosing Control

◎ High-Capacity Hopper

Accurate Automated Durable Corrosion-Resistant

Built for municipal and industrial water treatment, the Automatic PAC Dosing System SUS304 1000L Agitator 220/380V—branded as the QPL3 powder dosing machine—combines corrosion-resistant SUS304 construction, a 1000L mixing tank and selectable 220/380V operation to ensure durability and flexible installation. Its automatic metering, PLC-controlled dosing, powerful agitator to prevent caking, sealed feed ports and easy-clean design deliver precise, repeatable PAC dosing with minimal maintenance. The result is improved coagulation efficiency, reduced chemical waste, simple integration into existing plants and reliable, low-maintenance performance under harsh operating conditions, making the QPL3 powder dosing machine an efficient solution for water treatment facilities.

Material introduction

The QPL3 powder dosing machine features a SUS304 stainless steel 1000L tank and wetted components, offering strong corrosion resistance and extended service life for PAC/PAM dosing. Critical contact parts such as the hopper, agitator shaft and impeller are fabricated from SUS304 (with PP options available for highly aggressive powders), while seals and bearings use imported, corrosion-resistant materials to ensure accurate, low-wear metering. Drive and electrical elements (220/380V) are mounted in a rugged enclosure on a stainless frame to withstand industrial conditions and simplify maintenance.

◎ SUS304 Stainless Model

◎ PP Contact Model

◎ Hybrid Sealed Precision Model

FAQ

What is the "Automatic PAC Dosing System SUS304 1000L Agitator 220/380V" and what does it do?

It is an automated chemical dosing package built around a 1000 L SUS304 (stainless steel) storage tank with an agitator, level detection, a dosing pump and a control panel powered for 220/380 V supply. It stores and continuously mixes polyaluminium chloride (PAC) coagulant and delivers accurately metered doses to a water or wastewater stream for coagulation/flocculation. The system reduces manual handling, improves dosing consistency and protects the chemical from settling or stratification.

What are the main components and key specifications I should expect?

Typical components include a 1000 L SUS304 tank, vertical agitator with stainless shaft and impeller, automatic level sensor(s), chemical dosing pump (e.g., diaphragm or peristaltic), control panel with automatic/manual modes and alarms, inlet/outlet piping with strainers and ball valves, and optional flow-proportional or feedback control. Key specs: 1000 L capacity, corrosion-resistant SUS304 construction, 220/380 V power for motor and control, adjustable agitation speed, and dosing accuracy depending on pump type (typical dosing pumps deliver precise flow with repeatability in the low percent range).

In which application scenarios is this system commonly used?

Common applications include: - Municipal drinking water and wastewater treatment (primary coagulation and sludge conditioning) - Industrial effluent treatment (textile, paper, tannery, dye works) - Sludge dewatering and thickening processes - Cooling tower and process water clarification - Reservoirs, ponds and reuse water treatment for algae and turbidity control - Food and beverage process water where PAC is an approved coagulant It’s used wherever controlled PAC dosing improves solids removal or clarifies water.

How is the system normally installed and operated (power, control modes, dosing methods)?

Installation requires a level, ventilated area with chemical-resistant secondary containment. Connect electrical supply (select 220 V single-phase or 380 V three-phase according to motor/control), plumbing to chemical suction and discharge lines, and a drain/overflow. Operation modes typically include manual, timed, and automatic (level-, flow- or feedback-proportional). Set agitation to keep PAC uniformly suspended, set pump stroke/flow or dosing rate, and enable alarms for low level, overflow or pump fault. Commissioning should include leak checks, pump priming and verification of dosing rate against a calibrated flow.

What routine maintenance and PAC handling/storage practices are recommended?

Maintenance: inspect and clean strainers and suction filters, check seals and mechanical connections, monitor and replace wear parts on the dosing pump (diaphragm, valves, tubing) on the manufacturer’s schedule, test level sensors and alarms, and periodically clean tank interior to remove settled solids if they form. PAC handling: keep the tank covered, store PAC concentrate at recommended temperature, avoid long stagnation (continuous or periodic agitation helps), wear PPE when handling PAC, and use dedicated, chemical-resistant hoses/fittings. Follow local regulations for chemical storage and secondary containment.

What safety, chemical compatibility and troubleshooting points should I know?

Safety: PAC is a coagulant with mild corrosivity—use gloves, eye protection and ventilation for concentrated handling; ensure spill containment and neutralization materials are available. Compatibility: system materials (SUS304, chemical-grade hoses, pump wetted parts) are selected for PAC; avoid dosing strong acids, oxidizers or solvents unless equipment is specified for them. Troubleshooting: if dosing is inconsistent check suction strainers, air leaks in suction line, worn pump parts, blocked nozzles, insufficient agitation (leading to settled PAC), or faulty level sensors. Alarms and simple flow checks during commissioning simplify identifying faults.
