Auto Ind. Color Paint Mixer with Agit. & Milling, SUS304

Under the warm glow of the production floor, the Auto Ind. Color Paint Mixer with Agit. & Milling (SUS304) hums like a well-rehearsed orchestra, blending pigments into flawless, repeatable hues. Its robust SUS304 stainless frame and precision agitator with milling action turn stubborn clumps into silky, homogeneous paint while whispering efficiency and durability. Watch color come alive—fast, clean, and consistent—so every can that leaves your line carries the same perfect shade.

brand name:

QILEE

Shipping:

Support Sea freight

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-1(sets):30(days),>1(sets):To be negotiated(days)

Place of Origin:

China

Inquiry

Write a Review

Rarefied Liquid

650L

Medium Viscosity

300L

Diameter of Blade

160mm

Diameter of shaf

25mm

Length of shaft

800mm

Material

SUS304

Capacity

5 L

Power (kW)

1 kW

dimension(l*w*h)

Customized

additional capabilities

Milling

product type

Liquid

material processed

Chemicals

mixer type

Agitator

voltage

220/380V

Power

0.25KW

Product name

Liquid Paint Mixing Machine

weight (kg)

warranty

1 Year

place of origin

Shanghai, China

Precision Mixing, Hygienic SUS304

The Portable mixer with SUS304 paddles and shaft combines high-speed milling and gentle agitation to deliver smooth, even color paint mixing with consistent pigment dispersion and long service life. Its compact, corrosion-resistant stainless steel construction, robust agitator support for large or deep tanks, and options for vertical, side-entry or portable styles — plus SUS316 or rubber coating if needed — ensure hygienic operation and durable performance, all packed in standard export cartons for safe delivery. Selectable electric or pneumatic agitators and ex-proof motor options, quick 3–20 day lead times, and expert model-selection support reduce downtime and make the system easy to install, maintain, and scale to your production needs.

Automatic SUS304 Paint Mixer

The Auto Ind. Color Paint Mixer with Agit. & Milling, fabricated in SUS304, is a Portable mixer that provides smooth, even mixing and milling for liquid paints and industrial suspensions, backed by a strong agitator support suitable for large or deep tanks. Core structural attributes include stainless-steel paddles and shafts, selectable shaft lengths, blade diameters and reduction ratios, and optional SUS316 or rubber-coated parts plus electric or pneumatic drives and explosion‑proof motor choices. These functional and extended features deliver corrosion resistance, long service life, efficient dispersion, low maintenance and flexible installation (vertical, side-entry or portable), offering a customizable, value-focused solution for paint, chemical dosing and water/wastewater applications.

Automatic Industrial Paint Mixer

This automatic industrial color paint mixing machine features SUS304 paddles and shaft for durable, smooth running and even mixing, with strong agitator support suited for large or deep tanks. It is offered as a Portable mixer, as well as vertical and side-entry types, and can be supplied with electric or pneumatic drives and explosion-proof motors to meet needs in water treatment, sewage, reaction tanks and industrial paint or chemical agitation. Multiple models provide varied shaft lengths, blade diameters and power ratings for different maximum volumes, and material upgrades such as SUS316 or rubber coating are available on request.

◎ Stainless Steel Durability

◎ Versatile Installation Options

◎ Customizable Power Choices

Precision Efficiency Durability Consistency

Built by a brand with decades of industrial mixing expertise, the Auto Ind. Color Paint Mixer with Agit. & Milling is engineered from SUS304 stainless steel with precision-milled agitators and automated controls for repeatable, high-quality color dispersion. Product functions include automated batch mixing, high-shear milling, variable-speed agitation, and easy-clean sanitary surfaces, while product highlights feature a compact footprint, user-friendly touch controls, and integrated safety interlocks. As a Portable mixer it delivers fast, uniform pigment dispersion, corrosion resistance, low maintenance, reduced cycle times and portable flexibility that minimizes production downtime and ensures consistent, scalable paint quality.

Material introduction

The Auto Ind. Color Paint Mixer is built with SUS304 stainless steel paddles and shaft to ensure corrosion resistance and long service life in paint and chemical mixing. For harsher media the design can be upgraded to SUS316 or fitted with rubber coating on contact surfaces, while milling and agitator support structures use robust stainless components for reliable operation. As a Portable mixer option it features a sturdy support and compact construction that maintains smooth, even mixing and simplifies maintenance on site.

◎ SUS304 Corrosion-Resistant Hygienic

◎ SUS316 Chemical-Resistant Upgrade

◎ Rubber-Coated Wear-Protective Finish

FAQ

What is the Auto Ind. Color Paint Mixer with Agit. & Milling, SUS304 and what are its main advantages?

The machine is an automated industrial mixer combining high-shear agitation and inline or batch milling for dispersing pigments into paint, coatings and related fluids. Constructed in SUS304 stainless steel, it offers good corrosion resistance, hygienic surfaces, easy cleaning, and long service life. Advantages include faster, more uniform color dispersion, reduced manual labor, repeatable recipes, and integrated milling to break down pigment agglomerates for stable, high-quality finishes.

What types of products and materials can I process with this mixer?

It is designed for solvent‑ and water‑based paints, lacquers, varnishes, industrial coatings, pigments concentrates, inks, primers and some adhesives. It works well for dispersing organic and inorganic pigments, fillers and extenders. Very strongly corrosive chemicals or materials requiring exotic metallurgy may need SUS316L or special linings—verify chemical compatibility before use.

How is the machine typically used — what are the basic operating steps?

Typical workflow: load base resin/solvent into the vessel, add pigments and additives (often pre-wetted or pre-mixed), start low-speed agitation to wet solids, then engage milling section (or increase shear) to achieve target particle size and viscosity. Monitor temperature, viscosity and dispersion quality, then de-aerate and transfer or let settle as required. Many units include automated recipes, timers and interlocks to reproduce settings across batches.

What cleaning and maintenance practices are recommended?

Clean immediately after each product change using appropriate solvents or water-based cleaners, running the agitator and flushing the milling chamber. Periodically check and replace seals, gaskets, milling media (if applicable), bearings and agitator shafts. Inspect SUS304 surfaces for wear and damage; for heavy chemical exposure, consider more frequent inspections. Follow the manufacturer’s preventive maintenance schedule and keep spare parts on hand to minimize downtime.

What are typical capacity, scale and installation considerations?

Capacities vary by model — from small lab/demo units (liters) to production tanks (hundreds to thousands of liters). Power, floor loading, ventilation, feed lines and appropriate waste handling must be planned. Installation usually requires level concrete flooring, electrical service sized to motor ratings, grounding, and adequate exhaust for solvent fumes. For integration into production lines, confirm inlet/outlet connections, pump compatibility and automation/control interfaces.

How do I troubleshoot common problems like poor dispersion, excess heat or vibration?

Poor dispersion: check pigment pre-wetting, increase milling time or shear, verify correct milling media and gap settings, and ensure solids loading is within recommended range. Excess heat: reduce rotor speed, add cooling (jacket or external heat exchanger), or process in shorter cycles to avoid solvent evaporation. Vibration/noise: inspect bearings, imbalance of agitator or worn milling parts; tighten mountings and replace damaged components. Always stop the machine and follow lockout procedures before inspecting rotating parts.
