Auto Small Vacuum Powder Filler 500L/h 100-1000kg/h 20kW 1yr 1

Auto Small Vacuum Powder Filler 500L/h 100-1000kg/h 20kW 1yr 2

Auto Small Vacuum Powder Filler 500L/h 100-1000kg/h 20kW 1yr 3

Auto Small Vacuum Powder Filler 500L/h 100-1000kg/h 20kW 1yr 4

Auto Small Vacuum Powder Filler 500L/h 100-1000kg/h 20kW 1yr 5

Auto Small Vacuum Powder Filler 500L/h 100-1000kg/h 20kW 1yr 6

Auto Small Vacuum Powder Filler 500L/h 100-1000kg/h 20kW 1yr

Short description:

A compact automatic vacuum powder filler for fast, clean dosing of powders. It delivers 500 L/h and 100–1000 kg/h output with a 20 kW drive for stable, high-throughput work. Easy to run, low-dust operation and covered by a 1-year warranty.

Selling points that impress:

- High output: 500 L/h and 100–1000 kg/h capacity.

- Strong power: 20 kW drive for steady, continuous filling.

- Vacuum feed: low dust and less contamination.

- Automatic operation: cuts labor and speeds production.

- Space-saving small design: fits tight plant layouts.

- One-year warranty: gives buyers confidence and support.

Shipping:

Support Sea freight

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-1(sets):60(days),>1(sets):To be negotiated(days)

Place of Origin:

China

Inquiry

Write a Review

Floor area Length*Width

12.0m*6.0m

Total powder

20KW

Dissolving tank Diameter/Height

2.6m/2.5m

Treating Capacity(kg/h)

100-1000

Silo Diameter/Height

4.0m/11m

Silo volume(m3)

10-300

Processing Type

desalination

Power(W)

10 kW

Product name

Vacuum Filling Machine For Powder

Weight

1000

Voltage

220 V, 380 V

weight (kg)

1000

productivity

500L/Hour

warranty

1 Year

Precise Hygienic Compact Reliable

The Lime powder dosing system delivers high-efficiency, dust-free pneumatic conveying and precise metering—handling small-volume needs up to 500 L/h and heavy-duty feeds of 100–1000 kg/h to keep chemical and water-treatment processes consistent. Constructed in epoxy‑painted carbon steel (stainless steel optional) with modular silos, compact floor footprint, bin‑bottom activation and bag filters, its robust shape and quality materials simplify cleaning and preserve powder integrity. Standard export carton packaging, 3–20 day delivery, a 1‑year warranty and optional inlet-water control or lime-dissolving modules reduce installation time and operational downtime.

Compact Automated Precision Filler

The Auto Small Vacuum Powder Filler (500 L/h; 100–1000 kg/h capacity, 20 kW) functions as a Lime powder dosing system, using vacuum pickup and pneumatic conveying to deliver dust-free, accurate metering and high-throughput dry chemical transfer. Built with carbon-steel epoxy paint (stainless steel optional), bag filtration, bin-bottom activation and adjustable screw feeders, it includes optional inlet water control, lime dissolving tank and mixer to enable on-site slurrying while reducing contamination and maintenance. Designed for modular silos (10–100 m3) and compact floor footprints, the unit combines vacuum pickup, metering, pneumatic transport and screw discharge for reliable continuous dosing with simple controls and a one-year warranty.

Automatic Compact High Throughput

The Auto Small Vacuum Powder Filler is a vacuum filling and pneumatic conveying machine for high-volume dry chemicals such as lime, delivering dosing rates from 50–2000 L/h and model capacities up to 1000 kg/h with 20 kW drive power. As a Lime powder dosing system it combines 10–100 m3 silos, bin-bottom activation, powder metering and transporting, and a bag filter to ensure low-dust handling. Built in carbon steel with epoxy paint (stainless steel optional), it offers optional inlet water control, lime dissolving and mixing tanks, and typical delivery within 3–20 days.

◎ Compact Vacuum Filler

◎ Low Dust Transport

◎ Modular Dosing System

Efficient Precise Versatile Reliable

Developed by a specialized OEM with decades of process-engineering experience, the Auto Small Vacuum Powder Filler blends robust stainless-steel construction, PLC/HMI controls and precision metering to satisfy strict industrial dosing needs. As a Lime powder dosing system it delivers 500 L/h (100–1,000 kg/h) throughput driven by a 20 kW motor with vacuum transfer, gravimetric accuracy and quick-clean features, plus a 1-year warranty for production confidence. Key features and advantages include automatic vacuum feeding, adjustable dosing range, touch-screen recipe control, low-dust enclosure, energy-efficient motors and minimal maintenance requirements, resulting in high accuracy, fast changeovers and reliable continuous operation for small-to-medium lines.

Material introduction

The Auto Small Vacuum Powder Filler is constructed mainly from carbon steel with a durable epoxy paint finish, while stainless steel is offered as an option for highly corrosive or hygienic applications, making it well suited as a Lime powder dosing system. Critical wear parts such as the screw conveyors, bin bottom activation device, and pneumatic transport components use abrasion-resistant metals and chemically compatible seals to withstand lime’s alkalinity and minimize dust generation through the integrated bag filter. These material choices, together with optional inlet water control and dissolving tank configurations, extend service life, simplify maintenance, and ensure reliable, low-dust dosing performance.

◎ material introduction 1

◎ material introduction 2

◎ material introduction 3

FAQ

What do the listed capacity numbers (500 L/h and 100–1000 kg/h) mean, and how do I estimate the actual throughput for my powder?

The specifications show both a volumetric rate (500 liters per hour) and a mass throughput range (100–1000 kilograms per hour). Actual kg/h depends on your material’s bulk density. To estimate: throughput (kg/h) = volumetric rate (L/h) × bulk density (kg/L). Example: a powder with bulk density 0.6 kg/L at 500 L/h → about 300 kg/h. The 100–1000 kg/h range indicates the machine’s flexible dosing capability across different powders and settings.

What types of powders and particle characteristics are suitable for this vacuum powder filler?

It works best with free‑flowing, non‑sticky powders such as flour, milk powder, coffee, chemical powders, pigments, and many industrial powders. Fine dusts are handled but may require dust control and filtration. Highly cohesive, wet, or agglomerated powders, and very large granules or flakes, can cause bridging or clogging and may need preconditioning (drying, sieving) or a different feeding solution.

How do I set up and integrate the filler into my production line?

Place the unit on a stable, level surface with adequate clearance for access and cleaning. Provide the correct electrical supply (the unit is rated at 20 kW—use appropriate three‑phase supply and proper grounding), and ensure compressed air and/or vacuum utilities if required by your model. Align the outlet to your downstream packaging (bags, drums, pouches, or auger filler) and synchronize via signals or PLC for automatic start/stop and indexing. Always follow the manufacturer’s installation manual and have qualified electricians/technicians handle wiring and integration.

What routine cleaning and maintenance are required to keep reliable performance?

Daily: remove and clean product contact parts (hopper, suction tubes) if switching products or to prevent buildup. Inspect seals and filters. Weekly: check vacuum pump oil level, clean/replace air and dust filters, inspect hoses for wear or leaks. Monthly: check wear parts (seals, gaskets, valves), tighten fasteners, and verify calibration. Replace consumables per the manufacturer’s recommendations. For food or pharma use, follow validated cleaning procedures to prevent cross‑contamination.

What are the common troubleshooting steps if throughput drops or the machine clogs?

Check vacuum level and pump operation first. Inspect suction hose and inlets for blockages or bridged material. Verify filters are not clogged and seals are intact (air leaks reduce vacuum). Confirm the powder hasn’t absorbed moisture or changed flow properties. Adjust dosing time, vacuum pressure, or feed settings, and if problem persists, clean the feeding components and restart. If electrical or mechanical faults occur, consult the manual or contact service.

Are there special safety or regulatory considerations (dust control, explosion risk, warranty)?

Yes. Many powders create combustible dust hazards; use an explosion‑protected (ATEX/IECEx) version or install appropriate dust collection, grounding, and inerting systems where required. Always ground the machine, use local exhaust ventilation, and provide operator PPE. The product typically includes a 1‑year warranty covering manufacturing defects; wear parts (seals, filters, hoses), damage from misuse, improper installation, or missing preventive maintenance are normally excluded. Keep records of maintenance and follow supplier guidance to preserve warranty coverage.
